BB-700 MIRCOM

Product Overview

The Mircom BB-700 is a large, 7-module capacity enclosure designed for the modular expansion of the FX-2000, FleX-Net, and BC-2000 series fire alarm systems. It is intended for surface or semi-flush mounting and is typically used when a system requires a significant number of LED annunciators, display modules, or internal adder cards (such as the ALC-252 or ALCN-792M) that cannot fit in the main panel chassis.

Key Features

• 7-Module Capacity: Specifically designed to hold up to seven (7) internal modules or display chassis units.
• Modular Integration: Houses main and adder modules such as the RAM-1032, RAX-1048, IPS-2424, and the DSPL-420 internal display.
• Hinged Door System: Includes a lockable, hinged door (typically the DOOR-700) with a Lexan window to allow for visibility of internal LEDs and displays while maintaining security.
• Durable Construction: Heavy-duty, cold-rolled steel with multiple knockouts on the top, bottom, and sides for flexible conduit entry.
• Dimensions: Approximately 26” H × 14.5” W × 4.5” D, providing ample room for wiring and internal battery storage if required.
• Standard Finish: Available in Red (standard) or White (with the "W" suffix).
