GSW GENTEX

Product Overview

The Gentex GSW is a high-output, low-profile White Strobe designed for indoor wall-mount notification. As a member of the Commander 5 Series, it utilizes a high-intensity Xenon flashtube to provide six field-selectable candela settings, reaching a maximum of 177 cd for large open areas or high-ambient noise environments. The GSW features a sleek white faceplate that blends into modern architectural interiors. It is engineered with the patented Super-Slide® bracket and Checkmate® instant voltage verification system, allowing for efficient pre-wiring and streamlined system testing without removing the device from the wall.

Key Features

• Device Type: Strobe Only (Visual Only).
• Mounting: Wall Mount Only.
• Color: White faceplate with Red "FIRE" lettering.
• Field-Selectable Candela: 15, 30, 75, 115, 150, or 177 cd.
• Operating Voltage: Nominal 24 VDC (Range 16–33 VDC).
• Super-Slide® Bracket: Specialized plastic bracket for easy pre-wiring and supervision testing.
• Checkmate®: Built-in terminals for instant voltage verification using a voltmeter.
• Synchronization: Supports 1Hz flash synchronization via Gentex AVSM or GTSM modules.
• Compliance: ANSI/UL 1971 Listed; ADA/NFPA compliant.
