WSSPKA24-15/75AWW GENTEX

Product Overview

The Gentex WSSPKA24-15/75AWW is a weatherproof, wall-mount Amber Lens Speaker/Strobe designed for Mass Notification Systems (MNS) and emergency communication in outdoor or high-moisture environments. This model features a White faceplate with White "ALERT" lettering, providing a clean, low-profile aesthetic for non-fire emergency signaling. It combines a high-fidelity speaker (25/70.7 VRMS selectable) with a fixed 15/75 candela Amber Xenon strobe. When installed with the required Gasket Plate (GP) and a compatible GBLP or GSB outdoor back box, it provides a NEMA 3R-rated seal against rain, snow, and dust.

Key Features

• Device Type: Weatherproof Speaker/Strobe (MNS).
• Lens Color: Amber (A).
• Faceplate: White with White "ALERT" text (WW suffix).
• Visual Output: Fixed 15/75 Candela (Intensity rated per UL 1638 for Amber).
• Speaker Voltage: Dual voltage (25 or 70.7 VRMS).
• Power Taps: Field-selectable at 1/8, 1/4, 1/2, 1, 2, and 4 Watts.
• Environmental Rating: NEMA 3R (Requires GOE-GP Gasket and GBLP/GSB Box).
• Synchronization: Supports 1Hz flash synchronization via Gentex AVSM or GTSM modules.
• Mounting: Surface mount specifically for outdoor or high-humidity areas (e.g., parking garages, loading docks).
• Compliance: ANSI/UL 1480 (Speakers) and ANSI/UL 1638 (Visual Signaling) Listed.
