GSSR GENTEX
Warranty Terms and Conditions

GSSR GENTEX

by GENTEX
Sold out
$76.46 - $76.46
$76.46
$76.46 - $76.46
$76.46
Availability :
Out of stock

Product Overview



The Gentex GSSR (Gentex Synchronization Splitter Relay) is a specialized accessory designed to manage and synchronize notification appliances across multiple circuits. It is engineered to allow for the synchronization of Gentex strobes, horns, and horn/strobes when used in conjunction with a master sync source or a compatible Fire Alarm Control Panel (FACP). The GSSR is particularly useful in large-scale installations where notification appliance circuits (NACs) must be expanded or split while maintaining the strict 1Hz flash synchronization required by ADA and NFPA 72.



Key Features



  • Device Type: Synchronization Splitter/Relay Module.
  • Function: Synchronizes 24 VDC Gentex appliances (strobe and horn/strobe) across multiple circuit runs.
  • Operating Voltage: 24 VDC Nominal.
  • Contact Rating: Designed to handle standard NAC current loads (refer to specific wiring diagram for amp limits).
  • Compatibility: Works with Gentex Commander series appliances and AVSM synchronization protocols.
  • Installation: Compact design allows for mounting within standard electrical back boxes or at the FACP.
  • Wiring: Features screw terminals for supervised in/out wiring (12–18 AWG).
  • Compliance: UL 864 Listed (Control Unit Accessories).
