AVSM-W GENTEX

Product Overview

The Gentex AVSM-W is a White synchronization control module designed to provide a 2-wire output solution for synchronized audible and visual notification. This module is essential for installations using Gentex Commander series appliances where independent horn silence is required over a single pair of field wires. By receiving separate inputs from the panel's horn and strobe circuits, the AVSM-W "multiplexes" the signal, allowing the audible portion to be deactivated while the strobes continue to flash at the code-required 1Hz rate. The white faceplate is ideal for healthcare, laboratory, or high-end commercial interiors where a standard red module is not desired.

Key Features

• Color: White faceplate (designated by "-W" in SKU).
• 2-Wire Capability: Converts a 4-wire input into a 2-wire output to the field, reducing copper costs and conduit fill.
• Independent Horn Silence: Supports muting the audible signal while maintaining strobe flash for ADA compliance.
• Voltage Range: Wide operating range of 8–33 VDC; compatible with 12V and 24V systems.
• Current Capacity: Rated for 3.0 Amps continuous and 5.0 Amps surge current.
• System Scalability: Features "Daisy Chain" synchronization ports to link multiple AVSM modules across different zones.
• Temporal Pattern: Automatically generates the ANSI S3.41 Temporal 3 pattern for horns.
• Mounting: Designed for a 4" x 4" x 2-1/8" deep backbox.
• Certification: UL 464 and UL 1971 Listed.
