SPS-PSN-64 SPACE AGE

Product Overview

The Silent Knight SPS-PSN-64 (housed in a custom premium enclosure by Space Age Electronics) is a high-efficiency, 6-amp regulated Notification Appliance Circuit (NAC) power expander designed to deliver stable power distribution for demanding life safety setups. Operating on a universal 120 or 240 VAC input, this booster panel supplies a total of 6 amps of continuous power across four independent, power-limited outputs, with each circuit capable of driving up to 3 amps. Designed for seamless system expansions, the unit features built-in synchronization protocols for System Sensor, Wheelock, and Gentex notification appliances. Onboard DIP switches allow field technicians to easily configure Class A or Class B wiring topologies, choose trouble memory modes, and adjust AC loss report delays. The robust red steel cabinet provides an orderly internal arrangement for field wiring and provides adequate structural clearance to store up to two 18Ah backup batteries internally.

Key Features

• 6-Amp Regulated Output: Distributes a total of 6 amps of continuous notification power across four onboard circuits to drive strobes, horns, and chimes.
• Universal Strobe Synchronization: Built-in synchronization capabilities for System Sensor, Wheelock, and Gentex appliances, eliminating the need for external sync modules.
• Flexible Circuit Configurations: Onboard DIP switches facilitate individual loop setup for Class A (Style Z) or Class B (Style Y) supervised circuits without complex programming.
• Comprehensive Fault Tracking: Features dedicated 5A trouble relays alongside visual diagnostic LEDs to trace ground faults, AC loss, and low battery status.
• Custom Space Age Cabinetry: Encased in a heavy-duty, red industrial steel enclosure that streamlines wire routing, protects internals, and accommodates 18Ah backup batteries.
• Selectable AC Delay: Allows programmable delay intervals for reporting AC power failures, preventing nuisance alarms during brief utility brownouts.
