GEC24-177WR GENTEX
Conditions générales de garantie

GEC24-177WR GENTEX

par GENTEX
$59.89 - $59.89
$59.89
$59.89 - $59.89
$59.89
Disponibilité :
26 en stock, prêt à être expédié

Product Overview



The Gentex GEC24-177WR is a high-intensity, low-profile Horn/Strobe combination designed for wall-mount applications in large or high-ambient noise areas. This specific model features a White faceplate with Red "FIRE" lettering and a fixed 177 candela strobe. Operating at 24 VDC, it combines a powerful 3100 Hz audible signal with a high-output visual alarm to ensure maximum coverage. The unit features the patented "Super-Slide" mounting bracket, which allows for easy pre-wiring and "Checkmate" voltage verification, ensuring the system is functional before the head is even attached.



Key Features



  • Device Type: High-Intensity Horn/Strobe (Wall Mount).
  • Color: White faceplate with Red "FIRE" text (WR suffix).
  • Strobe Output: Fixed 177 Candela (High-intensity).
  • Audible Output: Switch-selectable High/Low dBA; options for Temporal 3, Continuous, and Mechanical tones (3100 Hz).
  • Voltage: Nominal 24 VDC (Operating range 16–33 VDC).
  • Installation: Super-Slide® Bracket for easy supervision testing and Checkmate® instant voltage verification.
  • Synchronization: Supports synchronization via Gentex AVSM module or compatible FACP protocol.
  • Dimensions: 5.0" H x 4.5" W x 2.5" D.
  • Compliance: UL 464 and UL 1971 Listed; ADA/NFPA compliant.
