GES3-24PWR GENTEX

Product Overview

The Gentex GES3-24PWR is a low-profile, wall-mount visual notification strobe designed for indoor use in 24 VDC systems. This "Plain" model features a White faceplate with no "FIRE" lettering, making it ideal for non-fire signaling applications such as security alerts, weather warnings, or mass notification. It features five field-selectable candela settings, allowing for versatile application in various room sizes. The unit utilizes the patented plastic Super-Slide® mounting bracket and Checkmate® instant voltage verification system to streamline installation and ensure system integrity without removing the device from the wall.

Key Features

• Device Type: Strobe (Visual Only).
• Faceplate: Plain White (No "FIRE" markings).
• Field-Selectable Candela: 15, 30, 60, 75, or 110 cd.
• Operating Voltage: Nominal 24 VDC (Range 16–33 VDC).
• Super-Slide® Bracket: Specialized plastic bracket for efficient pre-wiring and supervision testing.
• Checkmate®: Built-in terminals for instant voltage verification using a voltmeter.
• Synchronization: Supports 1Hz flash synchronization via the Gentex AVSM module or compatible FACP protocol.
• Dimensions: 5.0" H x 4.5" W x 2.5" D.
• Compliance: ANSI/UL 1971 Listed; ADA/NFPA compliant.
