GHSW GENTEX

Product Overview

The Gentex GHSW is a high-output, low-profile Horn/Strobe combination designed specifically for wall-mount indoor applications. Part of the Commander 5 Series, this unit features a White faceplate and uses a high-intensity Xenon flashtube to provide six field-selectable candela settings, including a high-intensity 177 cd output for large areas. It provides a versatile audible signal with multiple tones including Temporal 3, Temporal 4, and mechanical patterns. The GHSW incorporates the patented Super-Slide® mounting bracket and Checkmate® instant voltage verification system, allowing installers to pre-wire the system and verify voltage without the device being attached.

Key Features

• Device Type: Horn/Strobe Combination (Wall-Mount Only).
• Light Source: Xenon Flashtube.
• Field-Selectable Candela: 15, 30, 75, 115, 150, or 177 cd.
• Color: White faceplate with Red "FIRE" lettering.
• Operating Voltage: Nominal 24 VDC (Range 16–33 VDC).
• Audible Output: Switch-selectable tones including Temporal 3, Temporal 4, Continuous, Mechanical, and Chime.
• Installation: Super-Slide® bracket for easy supervision and Checkmate® for instant voltage testing.
• Synchronization: Supports synchronization via Gentex AVSM or GTSM modules.
• Compliance: ANSI/UL 464, ANSI/UL 1971, and CAN/ULC listed.
